SPACER SET AIR COOLED R4SSET FOR SATURN 2
Return to Retreading

Every spacer you need to rebuild a Saturn II rasp head, in one box.

The R4SSET is a complete 24-piece set of Pincott® air-cooled spacers for 9" diameter, 4-segment rasp hubs, including B&J Saturn II and R4 hub assemblies. It contains twenty 3/8" double spacers and four 3/16" single spacers, the full count needed to re-space a Saturn II hub. Unlike standard aluminum I-beam spacers, these are cross-ventilated: they move air and buffed crumb through the rasp head to keep blades cool and the buff texture consistent. Replacing all the spacers at once also gives you even blade spacing across the whole hub, which you can’t get by mixing new spacers with worn ones.

Key Features

  • Complete rebuild set: 20 × R4S38DL (3/8" double) + 4 × R4S316SL (3/16" single), the exact count for a Saturn II rasp head
  • Air-cooled alternative to aluminum I-beam spacers: cross-ventilation vents heat and cut rubber, which helps blades hold their temper
  • Fits 9" 4-segment hubs: B&J Saturn II, R4-style hubs, and the Pincott 408106 Bandag-style hub
  • Replace as a set: even wear across all positions means uniform blade spacing and a cleaner buff
  • Works with R4-series blades: Pincott PTR416, PTR420, PTR425, Smart II, and Ultra II

Technical Specifications

Spec Detail
Manufacturer Pincott®
McGee Part # R4SSET
Set Contents 20 × R4S38DL (3/8" double, Ascot 613-00438); 4 × R4S316SL (3/16" single, Ascot 613-04316)
Total Pieces 24
Spacer Type Standard Series Air-Cooled
Hub Fit 9" diameter, 4-segment: B&J Saturn II, R4-style, Pincott 408106
Alternative To B&J 111328 (3/8" I-beam) ×20 and 111330 (3/16" I-beam) ×4
Compatible Blades Pincott PTR416 / PTR420 / PTR425, Smart II, Ultra II; B&J R4-16 / R4-20 / R4-25, Apollo II; Italmatic I-4-16 / I-4-20 / I-4-25
Pins Not included. Saturn II rebuild requires 8 × 5/16" × 3-3/4" pins (McGee PIN516334)

FAQ

What do I need to fully rebuild a B&J Saturn II rasp hub?
You need 8 pins (5/16" × 3-3/4"), twenty 3/8" spacers, and four 3/16" spacers. The R4SSET covers all 24 spacers. Add 8 × PIN516334 pins to complete the rebuild if your pins are wonr.

Should I replace spacers and pins together?
Yes, for best performance. Worn pins develop grooves from blade refills, and worn spacers wear unevenly, so mixing new parts with old ones throws off blade spacing. Replace both when you see bent or grooved pins, uneven spacer thickness, rubber buildup, or cracks.

Will this set fit a Bandag buffer?
Yes, when the buffer runs a 9" 4-segment hub such as the Pincott 408106, which takes the same 20 + 4 spacer configuration. Call McGee to confirm your hub model if you’re unsure.
