O RING SEAL VALVE ALUM 75 DEG 1.38"
Return to Supplies TPMS
Upgrade or replace your heavy-duty fleet valves with the TPMS543E Heavy-Duty Aluminum Clamp-In Tire Valve. Engineered specifically for commercial trucks, trailers, and buses, this premium metal valve features a precise 75-degree bend to allow easy inflation and pressure checks on deep-dish or dual-wheel configurations. Built with a high-grade O-ring rubber seal, it provides an airtight, leak-proof fitment capable of handling the demanding pressures of long-haul commercial transport.
Key Features & Benefits
- Heavy-Duty Construction: Manufactured from premium, corrosion-resistant aluminum/metal alloy to withstand harsh road debris and extreme weather conditions.
- Leak-Proof Protection: Equipped with a high-quality rubber O-ring seal and locking nut for maximum air retention under high commercial tire pressures.
- Angled Accessibility: Designed with a 75° bend, making it significantly easier to access the valve stem on complex truck rims and inner dual setups.
- Universal Fitment: Engineered to seamlessly fit standard commercial truck wheels requiring a 0.382-inch valve hole.
Technical Specifications
- Part Number: TPMS543E / TR543E
- Material: Premium Aluminum Alloy
- Valve Angle: 75° Bend
- Effective Length: 1.38 inches (approx. 35mm)
- Rim Hole Compatibility: 0.382" (9.7mm) valve bore hole
- Seal Type: Inner O-Ring Clamp-In Seal
- Cross-Reference Industry Numbers: TR543E, TV-543E, VS-543E, 543E, ALL97728
What’s Included in the Box
- 1 x TPMS543E Aluminum Valve Stem (with pre-installed valve core)
- 1 x Rubber O-Ring Seal
- 1 x Secure Hex Locking Nut
- 1 x Protective Valve Cap
